Preparing installer media

Every installer is told, at build time, where to fetch its configuration. That URL does two jobs here:

1. It reaches the server. Any path works — POST and GET are answered on all of them, precisely so the URL baked into an ISO is never wrong.
2. Its path declares the format. A segment naming a known alias restricts the answer to documents of that format, so a kickstart client cannot be handed TOML.

Give each installer its own URL, and one server can answer for all of them.

Proxmox VE

$ proxmox-auto-install-assistant prepare-iso proxmox-ve.iso \
    --fetch-from http \
    --url http://SERVER:8000/proxmox/answer \
    --output proxmox-auto.iso

The installer POSTs a JSON inventory of the hardware it found and expects the answer in the response body. /proxmox/ restricts the reply to .toml documents; /answer on its own names no alias and constrains nothing, which is why an existing deployment keeps working unchanged.

To require a credential, prepare the ISO with a token and give the server the same one:

$ proxmox-auto-install-assistant prepare-iso proxmox-ve.iso \
    --fetch-from http --url http://SERVER:8000/proxmox/answer \
    --answer-auth-token 'a-long-random-string' --output proxmox-auto.iso

$ export RESCRIPTUM_ANSWER_TOKEN='a-long-random-string'

See Security for what that protects and what it does not.

Without rebuilding the ISO

Proxmox can also discover the URL at boot, which saves rebuilding media when the address changes:

• a DNS TXT record on proxmox-auto-installer.<your-domain>, or
• DHCP option 250.

Both are outside this server’s scope — it only has to be at the address they name.

Everything else, over iPXE

Other installers fetch their configuration, and identify themselves in the query string because iPXE substitutes its own variables into the URL before fetching:

Those become facts a document can be selected on, and their values also feed the substring haystack — so a document named after a MAC resolves whether the MAC arrived in a POST body or a query string.

A full iPXE script fragment:

#!ipxe
set base http://SERVER:8000
kernel ${base}/images/rhel9/vmlinuz inst.ks=${base}/rhel/ks?mac=${net0/mac}&serial=${serial}
initrd ${base}/images/rhel9/initrd.img
boot

rescriptum serves the answer, not the kernel — netbooting stays with whatever TFTP/HTTP server you already run.

Ubuntu and cloud-init NoCloud

cloud-init’s NoCloud datasource fetches two named files from the seed URL — user-data and meta-data — and skips the datasource entirely if either is missing. Since this server answers on any path, both requests would otherwise receive the same document and the install would never start.

The path’s last segment is available as the file fact, so the two are told apart with a selector:

# answers/groups/ubuntu-web/ubuntu.yaml
match:
  file: "user-data"
  product: "PowerEdge R6*"

# answers/groups/ubuntu-meta/ubuntu.yaml
match:
  file: "meta-data"

instance-id: iid-local01

Note the trailing slash in s=http://SERVER:8000/ubuntu/ — cloud-init appends the file name to it.

NoCloud can also expand __dmi.chassis-serial-number__ into the seed URL, which puts the machine’s identity in the path rather than the query. Path segments feed the haystack too, so a document named after that serial still resolves.

Choosing the alias

Any segment of the path may name the alias, so /rhel/ks, /ks, and /provision/rhel/node.cfg all restrict to kickstart. A URL naming none of them — /answer — constrains nothing.

The full table, and why seed is deliberately not an alias, is in the format reference.

Next

• How an answer is picked — what the server does with what the URL just told it.
• One document per operating system — the same machine, as Proxmox and as Debian, at the same time.
